precond_mod Module Reference

DERIVED TYPE precond: preconditioning for linear systems More...

Data Types
interface	clear
	destructor More...
interface	precond
	The type precond defines preconditioning for linear systems. More...

Functions/Subroutines
subroutine	precond_clear (pc)
type(precond) function	precond_create (K, type)
	Constructor for the type precond More...
subroutine, public	jacobi (invD, s)
	Jacobi preconditioner. More...
subroutine, public	reverse_cuthill_mackey (perm, permInv, s)
	Reverse CutHill Mac Kee algorithm. More...
subroutine, public	icc0 (LLT, s)
	Incomplete Choleski decomposition with 0 fill-in for s. More...

Detailed Description

DERIVED TYPE precond: preconditioning for linear systems

Preconditioning for linear systems with csr matrix.

Choral constants for preconditioning have the form PC_xxx.

Let a sparse matrix 'A' of type csr. A preconditionner 'pc' of type precond for 'A' is constructed with

pc = precond(a, type)

To solve \( Ax = b \) with the preconditionner 'pc' and with linear solver setting 'kry' of type krylov:

call solve(x, kry, b, A, pc)

see the solve documentation.

Author

Charles Pierre

Function/Subroutine Documentation

icc0()

subroutine, public precond_mod::icc0	(	type(csr), intent(out)	LLT,
		type(csr), intent(inout)	s
	)

Incomplete Choleski decomposition with 0 fill-in for s.

Definition at line 297 of file precond_mod.F90.

Here is the call graph for this function:

jacobi()

subroutine, public precond_mod::jacobi	(	real(rp), dimension(:), allocatable	invD,
		type(csr), intent(inout)	s
	)

Jacobi preconditioner.

Definition at line 173 of file precond_mod.F90.

Here is the call graph for this function:

precond_clear()

subroutine precond_mod::precond_clear ( type(precond), intent(inout)  pc )

private

Definition at line 100 of file precond_mod.F90.

precond_create()

type(precond) function precond_mod::precond_create ( type(csr), intent(inout)  K, integer, intent(in)  type  )

private

Constructor for the type precond

• OUTPUT:
  • pc = precond

• INPUT:
• type = preconditioning type
• K = csr matrix

Definition at line 121 of file precond_mod.F90.

Here is the call graph for this function:

reverse_cuthill_mackey()

subroutine, public precond_mod::reverse_cuthill_mackey	(	integer, dimension(:), allocatable	perm,
		integer, dimension(:), allocatable	permInv,
		type(csr), intent(in)	s
	)

Reverse CutHill Mac Kee algorithm.

Definition at line 201 of file precond_mod.F90.

Here is the call graph for this function:
